Features
-
VHF 136-174 50 - 1 W RF Output Power (Up to 50 W @ 50%, 25 W @ 100% Duty Cycle)
UHF 400-470 40 - 1W RF Output Power (up to 40W @ 50%, 25W @ 100% Duty Cycle)
Light, Compact and Space-Efficient
1.71-inch OLED with Icons and Numeric Displays
Thermal-Controlled Cooling Fan
Up to 32 Channels
Selectable Digital Protocol: DMR Tier II / NXDN Conventional*2
(programmable one at a time)
USB-A Connector for Audio Accessories
External In/Out Pin from DB25
Non-repeat Simplex / Semi-Duplex Mode for Analog and NXDN Digital*2
Hot Standby System Redundancy
Built-in IP Network Adapter
Unicast and Multicast Call Routing
SNMP protocol for network management
Supports G.711 Audio Codec (for Test console and Third-party Applications)
IP Remote Management (Monitor / Control / Programming / Test Console)
IPIF to External Applications (for IP Console, OTAP)
Built-in SIP IF (Digital Only)*1, *2
IP Remote Control Interface (IPRCI)
Enhanced Security (HTTPS)
CW ID
Multi-Site Conventional IP Network up to 16 Sites (for both Digital and Analog)*2
IP Networking Compatible with NXR-5000 (NXDN)*2, legacy KTI-3 (NXDN)*2
and KTI-5 (DMR)*2
Digital – Common
-
Built-in AMBE+2™ Vocoder
Mixed Analog / Digital Operation
Site Roaming with Beacon
RF-Link: NXDN / DMR
Repeat Encrypted Voice/Data (AES / DES / DMR Enhanced Encryption)
User List / Site Group Table
Digital – NXDN™ Mode
-
FDMA – Very narrow 6.25 kHz & narrow 12.5 kHz bandwidths
NXDN Conventional Operation*2
IP Network NXDN Voice Loggingn
NXDN Digital Voting*2
NXDN Digital Site Roaming
Radio Access Control*1
Digital – DMR Mode
-
TDMA 2-slot 12.5 kHz bandwidth equivalent to 6.25 kHz very narrow bandwidth
DMR Tier II Conventional Operation*2
DMR Digital Voting*2
DMR Site Roaming
Call Interruption
FM Modes – General
-
FM Conventional Operation
Multiple QT/DQT
Analog call routing
Voting
*1 Requires version upgrade of terminal to obtain compatibility with this model
*2 Software option
