KFC-X1756-1/2” 2-Way Speakers
Adjusting the composition of the materials used in the woofer cone, the rigidity of the diaphragm increases and realized the accurate sound signals.
The 1" Tweeter widens the sound field and controls interference, providing a rich vocal sound in front through the 6-1/2" speaker.
Multi-bracket is included to make installation easier in a varierty of vehicle types.
| Peak Power | 240W |
|---|---|
| RMS Power | 80W |
| Impedance | 4Ω |
| Sensitivity | 87 dB/ W at 1m |
| Frequency Response | 67Hz - 21kHz |
| Woofer | |
| Woofer Size | 6-1/2” (165mm) |
| Woofer Diaphragm | Injection PP cone |
| Tweeter | |
| Tweeter Size | 1” (25mm) |
| Tweeter Diaphragm | Soft Dome |
| Dimensions (without grill) | |
| Tweeter Height | 3/4" (19mm) |
| Mounting Depth | 2-3/16" (56mm) |
| ELECTRICAL | SYSTEM | ||
|---|---|---|---|
| PEAK INPUT POWER | 240 W | ||
| CTA Spec (CTA-2031 Compliant) | |||
| RMS POWER | 80 Watts RMS | ||
| IMPEDANCE | 4 Ω | ||
| SENSITIVITY | 87 dB/ W at 1 m | ||
| FREQUENCY RESPONSE | 67 Hz~21,000 Hz | ||
| COSMETIC | WOOFER | ||
| Diaphragm | P.P. Cone | ||
| Size | Oversized 165 mm | 6-1/2 inch | |
| Surround | Rubber | ||
| Basket | Steel | ||
| Magnet | Ferrite | ||
| TWEETER | |||
| Diaphragm | Soft Dome | ||
| Size | 25 mm | 1 inch | |
| Magnet | Nd | ||
| DIMENSION | with Grille | ||
| Width | 180.0 mm | 7-1/16 inch | |
| Height | 180.0 mm | 7-1/16 inch | |
| Depth | 84.2 mm | 3-5/16 inch | |
| without Grille | |||
| Width | 158.0 mm | 6-1/4 inch | |
| Height | 158.0 mm | 6-1/4 inch | |
| Depth | 75 mm | 2-15/16 inch | |
| Cut-out Diameter | 127.5 mm | 5 inch | |
| Tweeter Height | 19 mm | 3/4 inch | |
| Mounting Depth | 56.0 mm | 2-3/16 inch | |
| ACCESSORY | GRILLE | 2 pcs | |
| BRACKET | 2 pcs | ||
| Multi Bracket | |||
| SCREW SETS | |||
| Binding Head Tapping Screw | Φ4 x 25 mm | 8 pcs | |
| Binding Head Tapping Screw | Φ4 x 12 mm | 8 pcs | |
| Speed Nut | Φ4 | 8 pcs | |
| Speaker Cord | 0.3 m | 1 set | |
| Adhesive Tape | ○ | 1 set | |
| Instruction Manual with Template | ○ | 1 pc | |
| Warranty Card | ○ | 1 pc | |
